Dino-Lite Edge 5MP AM7915MZTL, 1 Stück

DLAM7915MZTL

Das Dino-Lite Edge 5MP AM7915MZTL ist ein Modell mit großem Arbeitsabstand (LWD) für Vergrößerungen von 10x - 140x und einer Bildauflösung von 5MP. Hohe Bildqualität, softwarebasierte Bildoptimierung (EDOF, EDR, AMR), eingebauter Polarisator, austauschbare Frontkappen und ein robustes Metallgehäuse machen es zu einem vielseitigen Handmikroskop für eine breite Palette von Anwendungen.

Merkmale: 5 MP, LWD, EDOF, EDR, AMR, FLC, POL (EDOF/EDR nur für Windows PC)

Kompatibel mit N3C-R (Ringlichtkappe).

1.169,00 € 1.391,11 €

Produktdetails

Beschreibung

High optical resolution
The superior optics adopted in the Edge series reveal fine details for most demanding microscopy applications.

5.0 Megapixels
Thanks to the low loss MJPEG compression, the advanced CMOS image sensor
allows to transmit fluid and crisp image with resolution up to 2592x1944.

Flexible LED Control (FLC)
The FLC maximizes illumination flexibility by offering independent on/off control of the four LED quadrants in addition to the 6 intensity level adjustment.

Automatic Magnification Reading (AMR)
Without stopping and checking the magnification for measurements, the AMR detects the magnification rate automatically, for more efficient, accurate, and pleasant measurements.

Extended Depth of Field (EDOF)
Viewing rough surface with height range out of depth of focus, the EDOF can
take several images at different focus and stack them automatically within a click.

Extended Dynamic Range (EDR)
Observing high contrast or reflective surface, the EDR can help to reveal the details
of dark or bright areas by stacking images taken at different exposure levels.

Long-Working-Distance (LWD) optics
The LWD optics yields more working space between the object and the microscope, making it ideal for applications such as repairing or assembly.

Adjustable polarizer
The built-in adjustable polarizer allows to remove freely the unwanted reflection
or glare from the object surface for a better contrast.

Scroll Lock
The scroll lock ensures the focus knob staying at the desired focus or
magnification position without worry of unintentional movement.

Robust housing
The metal housing made of aluminium alloy offers compelling advantages of protection and endurance.

Interchangeable caps
The interchangeable caps provide adaptability to numerous applications with
alternative lighting or object interface, such as but not limited to diffused-light, ringlight, and coaxial-light etc.

Model	AM7915MZTL Dino-Lite Edge
Interface	USB 2.0
Product Resolution	5M pixels (2560x1920)
Magnification	10x~140x
Frame Rate	10fps in 5MP/3MP/2MP, MJPEG 25fps in 1.3MP, MJPEG 30fps in VGA, MJPEG
Save Formats	Image: DinoCapture2.0: BMP, GIF, PNG, MNG, TIF, TGA, PCX, WBMP, JP2, JPC, JPG, PGX, RAS, PNM DinoXcope: PNG, JPEG Video: DinoCapture2.0: WMV, FLV, SWF DinoXcope: MOV
Polarizer	Yes
Microtouch	Yes
Lighting	8 white LEDs
Operating System Supported	Windows 7/8/10/11 macOS 10.14 or later (EDOF/EDR/DPQ are NOT controllable on macOS)
System Requirements	‧ Intel Core2 Duo @ 2.20 GHz/AMD Athlon X2 Dual Core BE-2400 (2.3GHz) ‧ 20GB available HD space ‧ 4GB available RAM or more ‧ 2GB video card or more ‧ CD-ROM drive for installation ‧ USB 2.0
Calibration Function	Yes
Measurement Function	Yes
Unit Dimension	10.5cm (H) x 3.2cm (D)
Unit Weight	138g

Weitere Informationen

Weitere Informationen
Verpackungseinheit	1 Stück
Hersteller	Dino-Lite
