Gradient Station™ Basiseinheit
B153-002
Basisgerät der Firma BioComp Instruments zur Erzeugung linearer Dichtegradienten und Fraktionierung von zentrifugierten Proben aus dem Ultrazentrifugenröhrchen. Das Röhrchen bleibt dabei unbeschädigt. Die Gradient Station™ kombiniert den Piston Gradient Fractionator™ und den Gradient Master™ in einem Sytem.
Alle technischen Daten, die Teile und das Zubehör sind identisch mit denen der einzelnen Instrumente. Für jede Röhrchengröße werden Röhrchenhalter benötigt. Diese müssen zusätzlich zum Grundgerät erworben werden.
Setzen Sie sich mit uns in Verbindung und wir werden die beste Konfiguration für Ihre Anwendung finden.
Produktdetails
Beschreibung
This hybrid instrument performs both gradient forming and fractionating.
The Gradient Station™ is a combination of Gradient Master™ and the Piston Gradient Fractionator™ in one compact, fully functional system. One element forms linear density gradients and the other fractionates them after centrifugation.
The performance of these two elements, is identical to the original instruments.
Whether you use them separately or in the hybrid Gradient Station™, the combination of the Gradient Master™ and the Piston Gradient Fractionator™ offers a quantum leap in speed, reproducibility and resolution.
Gradient Mixing
- Easy and Fast
- Highly reproducible
- Patented tilted-tube-rotation
- Large variety of predefined protocols
- Durable, robust construction
- Interchangeable tube holders for all common tube size
- Also suitable as blotting device for Southern-, Western- and Northern-blots
Fractionation
- Clean and easy fractionation
- High precision and reproducibility
- No puncturing of the tube
- High resolution by patented TrumpetTM Tip system
- Illumination system to visualize bands
- Cleaning in between fractions
- Integration of UV/VIS measuring cell (optional)
- Integration of Fraction Collector (optional)
- Interchangeable tube holders for all common tubes
Tube holders are not included in the base unit and need to be purchased separately.
For more informations, see our data sheet.
Needed Accessories
- MagnaBaseTM Tube Holder
- PGF Tube Holder
- Piston tip
- Cursor
- Marker Block
- Caps for centrifuge tubes (short/long Caps)
Included
- Combined Gradient MasterTM and Piston Gradient FractionatorTM Base Unit with all tools an spare parts
Gradient Station can be equipped with:
- Fraktion Collector
- TriaxTM Flow Cell (measuring cell for UV/VIS)
- PC (recording UV/VIS spectra)
Technical Data
Voltage | 220-240V (CE certified) |
Dimensions | 558,8mm x 254mm x 558,8mm (W/D/H) |
Weight | 23,6kg |
Weitere Informationen
Hersteller |
BioComp
|
---|---|
Typ |
Grundgerät
|
Gewicht | 0.000000 |
