Linkam Heiz-Kühl-Tisch für Infrared und FTIR, < -195°C to 600°C
Der FTIR600-Tisch wurde vom marktführenden Hochpräzisions-Tisch THMS600 übernommen und ermöglicht die Infrarotanalyse von Proben im Temperaturbereich < -195°C* bis zu 600°C und deckt damit alle Anwendungen von der Pharmazie bis zu Polymeren auf den meisten Benchtop-IR-Mikroskopsystemen ab (bitte fragen Sie nach dem IR windows kit). Alternative Materialien für die Sichtfenster wie Zinkselenid und Bariumfluorid sind ebenfalls erhältlich.
Produktdetails
Beschreibung
The FTIR600 stage can be mounted horizontally for IR microscopy setups and vertically for cabinet type IR spectroscopy. The silver block has a tapered hole to allow maximum transmittance of IR without interference.
The FTIR600 stages have been designed to be used in applications where rapid heating/cooling rates and high levels of accuracy and stability are required, and are supplied in three standard versions:
- FTIR600 for horizontal mounting to IR microscopes.
- FTIRSP600 for vertical mounting in horizontal IR beam spectrometers, incorporating a vertical sample holder and detachable base plate for either free-standing or attachment to a bracket in the spectrometer chamber.
- FTIR600MSO for mounting onto a motorised table with a 160 x 110mm recess.
FTIR600 Infra Red Systems Specifications
- Temperature range < -195°C to 600°C
- heating rates up to 150°C/min
- Fast cooling rates up to 100°C/min
- Temperature stability <0.01°C
- 16mm XY sample manipulation
- Sample area 22mm diameter
- Quick-release gas valves for atmospheric control
- Compatible with most IR systems.
- 100 Ohm platinum resistor sensor
- Light aperture 3mm diameter for high accuracy control
- Silver heating block for high thermal conductivity
- Direct injection of the coolant into the silver block
- Range of IR transparent windows available
- Objective lens working distance 4.8mm
- Can be used with all optical microscope techniques
- The stage body can be cooled with a water cooling pump for high temperature work (>300°C)
- Suitable for confocal, Laser Raman and X-ray
- Stage body size 135mm x 92mm x 21.7mm
Some FTIR sample windows such as KBR and ZnSe maybe up to 0.5mm and not 0.2mm as shown in diagram.
If you are using a light microscope, please gask for the STAGE CLAMPS options to check your microscope is compatible.
For information on transmitted light applications, please ask for the CONDENSER EXTENSION LENS options.
*Für die automatische Kühlung von Proben unter die Umgebungstemperatur bis auf -195C benötigen Sie das LNP96 - Flüssigstickstoff-Kühlsystem.
Weitere Modelle und Konfigurationen erhältlich. Für wietere Informationen und Beratung nehmen Sie bitte Kontakt mit uns auf.
