HFS probe systems

The sample is placed on the heating element and the probes are moved manually to make contact at the appropriate points. The probes have excellent positional resolution enabling precise contact points to be made easily. HFS probe systems can also be used vertically.

To cool samples from ambient down to < -195°C, add the LNP96 liquid nitrogen cooling pump.

An Introduction to the Linkam Probe Stages

HFS600E-PB4 Specifications

• Temperature range < -195°C to 600°C (cooling option required)
• Up to 150°C/min heating
• Temperature stability <0.01°C
• Sample area 22mm diameter
• Quick-release gas valves for atmospheric control
• 100ohm platinum resistor sensor
• Light aperture 2mm Ø
• Silver heating block for high thermal conductivity
• 22mm x 0.5mm quartz window
• Objective lens working distance 4.9mm
• Stage body can be water cooled for high temperature work ( >300°C)
• Suitable for confocal, Laser Raman, X-ray and other microscope techniques

For information on transmitted light applications, please ask for the CONDENSER EXTENSION LENS options.

For automatic cooling the sample below ambient temperature down to -195C you will need the LNP96 - Liquid Nitrogen Cooling Systems.

More models and configurations available. For more information and support please contact us!
